JLG
Mec
2591ES
Aerial Lift
22 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Engine
| Engine Model | 750 |
|---|---|
| Gross Power | 24.5 hp |
| Fuel Type | Dual |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Wheelbase | 91 in |
| Overall Length | 10 in |
| Overall Width | 70 in |
| Turning Radius | 84 in |
| Height w/ Rails | 98 in |
| Height w/o Rails | 78 in |
Performance
| Operating Weight | 9,100 lb |
|---|---|
| Max Speed | 3.5 mph |
| Tire Size | 30.4x10 |
| Hydraulic System Fluid Capacity | 18.0 gal |
| Tire Fill/Type | Foam |
| Fuel Capacity | 13.0 gal |
Platform
| Max Platform Height | 396 in |
|---|---|
| Max Platform Weight Capacity | 1,000 lb |
| Platform Inner Length | 115 in |
| Platform Inner Width | 65 in |
| Lift Time | 38.0 s |
| Deck Extension | 36 in |
| Lower Time | 42.0 s |
| Height of Rails | 44 in |
