JLG
Mec
2591ES
Aerial Lift
22 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Engine
| Battery Amp Hours | 370 |
|---|---|
| Number of Batteries | 6 |
| Charger Amps | 21 |
| Maximum Ground Bearing Pressure | 57 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Wheelbase | 93 in |
| Overall Length | 124 in |
| Overall Width | 71 in |
| Overall Height | 108 in |
| Turning Radius | 186 in |
| Height w/ Rails | 78 in |
| Height w/o Rails | 67 in |
| Platform Dimension B | 66 in |
| Platform Dimension A | 115 in |
Brakes & Steering
| Brakes Type | Spring Applied Hyd. Released Discs |
|---|
Performance
| Operating Weight | 9,760 lb |
|---|---|
| Max Speed | 3.0 mph |
| Tire Size | 240/55-17.5 |
| Hydraulic System Fluid Capacity | 8.6 gal |
| Tire Fill/Type | Non-marking |
| Platform Capacity | 1,000 lb |
| Drive Speed - Platform Lowered | 3.0 mph |
| Drive Speed - Platform Elevated | 0.4 mph |
| Hydraulic Pump Type | Single Section Gear Pump |
| Maximum Drive Height | 397 in |
| Maximum Lift Height | 397 in |
Platform
| Max Platform Height | 397 in |
|---|---|
| Max Platform Weight Capacity | 1,001 lb |
| Platform Inner Length | 36 in |
| Platform Inner Width | 65 in |
| Max Working Height | 468 in |
| Lift Time | 38.0 s |
| Deck Extension | 36 in |
| Lower Time | 42.0 s |
| Height of Rails | 44 in |
| Platform Railing Height | 69 in |
| Platform Capacity - Extension | 250 lb |
