JLG
Mec
2591ES
Aerial Lift
22 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Engine
| Engine Model | VSG-413 |
|---|---|
| Gross Power | 35.0 hp |
| Fuel Type | Dual |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Wheelbase | 98 in |
| Overall Length | 13 in |
| Overall Width | 91 in |
| Turning Radius | 135 in |
| Height w/o Rails | 69 in |
Performance
| Operating Weight | 10,400 lb |
|---|---|
| Max Speed | 3.5 mph |
| Tire Size | 12x16.5 |
| Hydraulic System Fluid Capacity | 20.0 gal |
| Fuel Capacity | 15.0 gal |
Platform
| Max Platform Height | 475 in |
|---|---|
| Max Platform Weight Capacity | 1,000 lb |
| Platform Inner Length | 126 in |
| Platform Inner Width | 71 in |
| Lift Time | 65.0 s |
| Deck Extension | 48 in |
| Lower Time | 35.0 s |
| Height of Rails | 44 in |
