JLG
Mec
2591ES
Aerial Lift
22 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Engine
| Battery Amp Hours | — |
|---|---|
| Charger Amps | 21 |
| Fuel tank | 4.0 gal |
| Maximum Ground Bearing Pressure | 61 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Wheelbase | 93 in |
| Overall Length | 122 in |
| Overall Width | 71 in |
| Overall Height | 111 in |
| Turning Radius | 187 in |
| Platform Dimension A | 117 in |
| Platform Dimension B | 66 in |
Brakes & Steering
| Brakes Type | Spring Applied Hyd. Released Discs |
|---|
Performance
| Operating Weight | 10,860 lb |
|---|---|
| Tire Size | 240/55 x 17.5 Non-Marking |
| Hydraulic System Fluid Capacity | 8.5 gal |
| Platform Capacity | 800 lb |
| Drive Speed - Platform Lowered | 3.0 mph |
| Drive Speed - Platform Elevated | 0.4 mph |
| Hydraulic Pump Type | Single Section Gear Pump |
| Maximum Drive Height | 360 in |
| Maximum Lift Height | 480 in |
Platform
| Max Platform Height | 71 in |
|---|---|
| Max Working Height | 480 in |
| Lift Time | 54.0 s |
| Lower Time | 50.0 s |
| Height of Rails | 46 in |
| Platform Railing Height | 552 in |
| Platform Capacity - Extension | 250 lb |
