936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
53 data points
Operating Specifications
| Fuel Capacity | 76.7 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 99.9 gal/min |
| Hydraulic System Fluid Capacity | 63.5 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 A |
| Hydraulic Pump Type | Variable Axial-Piston |
| Tire Size | 10.00-20 16 PR |
| Oscillating Axle Angle | 7 ° |
| Front Diff Fluid Capacity | 2.6 gal |
| Rear Diff Fluid Capacity | 3.7 gal |
Engine
| Engine Model | 4HK1X Tier III certified |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 159.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged and intercooled |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 104 in |
| Overall Width | 8 in |
| Tail Swing Radius | 93 in |
| Digging Depth | 230 in |
| Digging Reach | 377 in |
| Upper Structure Clearance | 49 in |
| Overall Width - Outriggers Down | 135 in |
Transmission
| Max Travel Speed | 21.8 mph |
|---|---|
| Transmission Type | Automatic shift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 230 in |
|---|---|
| Max Reach Along Ground | 377 in |
Bucket
| Reference Bucket Capacity | 0.99 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.50 yd³ |
| Minimum Bucket Capacity | 0.80 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|---|
| Swing Torque | 29,800 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 230 in |
|---|---|
| Max Cutting Height | 365 in |
| Max Reach Along Ground | 371 in |
| Max Loading Height | 254 in |
| Shipping Length of Unit | 354 in |
| Shipping Height of Unit | 124 in |
| Max Vertical Wall Dig Depth | 207 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 234 in |
|---|---|
| Max Cutting Height | 389 in |
| Max Reach Along Ground | 367 in |
| Max Loading Height | 275 in |
| Shipping Height of Unit | 127 in |
| Shipping Length of Unit | 347 in |
| Max Vertical Wall Dig Depth | 207 in |
