John Deere
Kubota
B2410
Tractor
22 specifications
1 / 5
Image 1 of 5
Specifications
56 data points
Engine
| Engine Model | 3TNV88C-NJT |
|---|---|
| Displacement | 96 in³ |
| Gross Power | 36.8 hp |
| Number of Cylinders | 3 |
| Aspiration | Turbocharged |
| Bore | 3 in |
| Stroke | 4 in |
| Engine Type | Direct Injection |
| Air cleaner | Dual element |
| Cooling system | Water pump |
| Rated Engine Speed | 2,500 rpm |
| Emissions compliance | Final Tier 4 |
| Lubrication | Pressurized |
| Fuel tank capacity | 8.5 gal |
| Power take-off (PTO) power | 30.4 hp |
| Compression ratio | 19.1:1 |
| Engine torque at rated speed | 75 lb-ft |
| Family | GYDXL1.57TDA |
| Engine Manufacturer | Yanmar |
| Cylinder liners | Cast-In-Block |
| Injection pump type | Direct Injection |
Hydraulic System
| Pump Type | Gear |
|---|---|
| Maximum operating pressure | 2,500 psi |
| Remote control valves available | Up to three |
| Draft control sensing | Position control |
| Hydraulic Type | Open Center |
| Pump rated output | Steering - 15 L/min Implement - 20.2 L/min |
Dimensions
| Wheelbase | 815 in |
|---|---|
| Shipping weight | 2,436 lb |
| Turning radius with brakes | 108 in |
| Turning radius without brakes | 119 in |
Transmission
| Brakes | Wet disc |
|---|---|
| Steering | Power steering |
| Differential lock | Yes |
| Final Drive Type | Bull Gear |
| Cruise control | Standard |
| Axle capacity | Front - 880 kg Rear - 1089 kg |
| Standard transmission; forward/reverse | Hydrostatic transmission (HST) |
| Creeper | No |
Fluid Capacities
| Crankcase with filter | 1.2 gal |
|---|
Tires & Wheels
| Rear Tires Size | R1 Ag 12.4-16 R3 Turf 14-17.5 R4 Industrial 14-17.5 R3 Turf Radial 300/70 R20 |
|---|---|
| Front Tires Size | R1 Ag 7.00-12 R3 Turf 23x8.50-14 R4 Industrial 23x8.50-14 R3 Turf Radial 200/60 R15 |
Electrical System
| Alternator (12-V) | 85 A |
|---|---|
| Battery size | 500 CCA |
| Starter size | 1.9 hp |
3-Point Hitch
| Lift capacity (24-in. behind link arms) | 1,356 lb |
|---|
Power Take-Off (PTO)
| Standard | Rear - 540 rpm Mid - 2000 rpm |
|---|---|
| Clutch | Independent |
| Control | Independent |
| Brake (for mid and rear PTO) | Wet disc |
Final Drive
| Final Drive Type | Spur Gear |
|---|---|
| Differential lock | Yes |
Fuel System
| Fuel System Type | Direct Injection |
|---|
Operator Station
| Gear shift location - console/floor | Left Hand Side |
|---|---|
| Platform - flat/straddle | Flat |
| Rollover protective structure | Foldable ASABE S478 |
