KubotaKubota
B2920
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 1,477 lb |
|---|---|
| Fuel Capacity | 6.4 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 1,301 lb |
| 3 Point Hitch Type | Cat I |
| Cooling System Fluid Capacity | 1.1 gal |
| Engine Oil Capacity | 0.8 gal |
Engine
| Engine Model | D1105 |
|---|---|
| Displacement | 69 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 24.0 hp |
| Number of Cylinders | 3 |
| Aspiration | E-TVCS liquid cooled |
| PTO Power | 18.0 hp |
Hydraulic System
| Pump Flow Capacity | 7.0 gal/min |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 60 in |
| Overall Length | 8 in |
| Tire Size | front 7-12 rear 11.2-16 |
| Width Outside Frame | 47 in |
Transmission
| Max Speed | 10.3 mph |
|---|---|
| Transmission Type | HST 2 range |
Axles
| Final Drive | Spur gear |
|---|
