John Deere
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
48 data points
Operating Specifications
| Fuel Capacity | 89.9 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 113.1 gal/min |
| Hydraulic System Fluid Capacity | 81.9 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 6.1 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 A |
| Hydraulic Pump Type | Variable Axial-Piston |
| Oscillating Axle Angle | 12 ° |
| Front Diff Fluid Capacity | 3.0 gal |
| Rear Diff Fluid Capacity | 3.5 gal |
Engine
| Engine Model | 6BG1T |
|---|---|
| Displacement | 396 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 148.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,600 rpm |
| Net Torque | 405 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 109 in |
| Overall Width | 8 in |
| Tail Swing Radius | 107 in |
| Digging Depth | 252 in |
| Digging Reach | 396 in |
| Upper Structure Clearance | 50 in |
| Overall Width - Outriggers Down | 146 in |
Transmission
| Max Travel Speed | 15.6 mph |
|---|---|
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Swing Mechanism
| Swing Speed | 14 rpm |
|---|---|
| Swing Torque | 43,217 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 253 in |
|---|---|
| Max Cutting Height | 389 in |
| Max Reach Along Ground | 393 in |
| Max Loading Height | 277 in |
| Shipping Length of Unit | 386 in |
| Shipping Height of Unit | 124 in |
| Max Vertical Wall Dig Depth | 229 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 240 in |
|---|---|
| Max Cutting Height | 404 in |
| Max Reach Along Ground | 380 in |
| Max Loading Height | 291 in |
| Shipping Height of Unit | 135 in |
| Shipping Length of Unit | 370 in |
| Max Vertical Wall Dig Depth | 210 in |
