John Deere
Takeuchi
TW40
Wheel Loader
9 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 12,059 lb |
|---|---|
| Tire Size | 365/70 R18 |
| Rated Bucket Capacity | 0.99 yd³ |
Engine
| Engine Model | 4TNV98CT |
|---|---|
| Displacement | 201 in³ |
| Net Power | 61.0 hp |
| Engine Make | YANMAR |
| Make | YANMAR |
| Torque | 206 lb-ft |
| Alternator | 80 A |
| System Voltage | 12 V |
| Rated Speed | 2,200 rpm |
| Transmission Type | Hydrostatic |
| Emission level | Tier 4 |
| Pump | Gear |
| Engine Output-Net | 69.8 hp |
Weights
| Operating Weight | 12,060 lb |
|---|
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Wheelbase | 85 in |
| Width Over Tires | 76 in |
| Length with Bucket on Ground | 214 in |
| Turning clearance circle | 288 in |
Transmission
| Transmission Type | Gear |
|---|---|
| Pump Flow | 17.7 gal/min |
Brakes & Steering
| Parking brake | Wet Disc |
|---|---|
| Brakes Type | Wet Disc & Drum |
| Actuation | Hydraulic |
Fluid Capacities
| Fuel Tank | 21.2 gal |
|---|---|
| Hydraulic Tank | 14.6 gal |
| Transmission | 0.2 gal |
| Heaped Capacity | 1.10 yd³ |
Bucket
| Dump Clearance at Max Raise | 101 in |
|---|
