John Deere
Hitachi
LX40-7
Wheel Loader
40 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 12,778 lb |
|---|---|
| Tire Size | 405/70 R18 |
| Rated Bucket Capacity | 0.99 yd³ |
Engine
| Engine Model | 4TNV98 |
|---|---|
| Displacement | 201 in³ |
| Net Power | 65.0 hp |
| Engine Make | YANMAR |
| Make | YANMAR |
| Torque | 175 lb-ft |
| Alternator | 80 A |
| System Voltage | 12 V |
| Rated Speed | 2,400 rpm |
| Transmission Type | Hydrostatic |
| Emission level | Tier 4 |
| Pump | Gear |
| Engine Output-Net | 64.4 hp |
Weights
| Operating Weight | 12,778 lb |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 85 in |
| Width Over Tires | 71 in |
| Length with Bucket on Ground | 219 in |
| Turning clearance circle | 360 in |
Transmission
| Transmission Type | Gear |
|---|---|
| Pump Flow | 20.4 gal/min |
Brakes & Steering
| Parking brake | Wet Disc |
|---|---|
| Brakes Type | Wet Disc & Drum |
| Actuation | Hydraulic |
Fluid Capacities
| Fuel Tank | 13.3 gal |
|---|---|
| Hydraulic Tank | 23.8 gal |
| Transmission | 0.3 gal |
| Heaped Capacity | 1.10 yd³ |
Bucket
| Dump Clearance at Max Raise | 104 in |
|---|
General Specifications
| Operating Weight | 12,778 (5,796) — Starting 2019 Model Year |
|---|---|
| Bucket Capacity | 1.0 - 2.1 (0.8 - 1.6) — Starting 2019 Model Year |
| Engine type | YANMAR 4TNV98 — Starting 2019 Model Year |
| Engine Power | 65 (48) — Starting 2019 Model Year |
| Max Dump Height | 8.6 (2.6) — Starting 2021 Model Year |
