John Deere
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 6,380 lb |
|---|---|
| Max Speed | 6.9 mph |
| Fuel Capacity | 18.8 gal |
| Tire Size | 10 x 16.5 |
Engine
| Engine Model | 4TNV86CHT |
|---|---|
| Displacement | 128 in³ |
| Power Measured @ | 2,600 rpm |
| Aspiration | Turbo |
| Max Torque | 153 lb-ft |
| Engine Make | Yanmar |
| Emissions Certification | Tier 4 |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Wheelbase | 42 in |
| Overall Height | 78 in |
| Length with Bucket | 128 in |
| Length w/o Bucket | 104 in |
| Hinge pin height - fully raised | 115 in |
General Specifications
| Engine Power HP (KW) | 65 (48.5) Starting 2019 Model Year |
|---|---|
| Operating Width IN. (CM) | 62.9 (160) Starting 2024 Model Year |
| OPERATING LOAD LBS. (KG) | 1,750 (795) Starting 2016 Model Year |
| Rated Operating Capacity LBS (KG) 50% | 1,750 (795) Starting 2024 Model Year |
| OPERATING WIDTH IN. (M) | 62.9 (1.60) Starting 2019 Model Year |
| SAE RATED OPERATING CAPACITY LBS. (KG) | 1,750 (795) Starting 2019 Model Year |
Loader
| Operating Load Rating | 1,750 lb |
|---|---|
| Operating Width | 63 in |
| Width without Bucket | 62,993 in |
