John Deere
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 8,133 lb |
|---|---|
| Max Speed | 11.0 mph |
| Fuel Capacity | 29.2 gal |
| Hydraulic System Fluid Capacity | 21.2 gal |
| Tire Size | 12 x 16.5 10 PR Extra Wall |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | E 5030HT |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,000 rpm |
| Number of Cylinders | 5 |
| Aspiration | Turbocharged and intercooled |
| Torque Measured @ | 2,050 rpm |
| Engine Make | John Deere PowerTech |
| Air cleaner | Dry dual element |
| Emissions Certification | EPA Interim Tier 4/EU Stage IIIB |
| Net Torque | 189 lb-ft |
| Net Torque Rise | — |
Hydraulic System
| Pump Flow Capacity | 33.1 gal/min |
|---|---|
| Hydraulic Horsepower-Standard Flow | 46.0 hp |
| Hydraulic Horsepower_High Flow | 72.0 hp |
| System Pressure at Couplers | 3,450 psi |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Wheelbase | 49 in |
| Reach at Max Lift and Dump | 33 in |
| Height - Top of ROPS/FOPS | 84 in |
| Length w/o Bucket | 119 in |
| Angle of departure | 28 ° |
| Length | 142 in |
| Hinge pin height, maximum height | 125 in |
| Turning Radius - TTS870 | 86 in |
Loader
| Operating Load Rating | 1,249 lb |
|---|---|
| Operating Width | 73 in |
| Tipping load (ISO 14397) | 5,200 lb |
| Boom breakout force | 5,000 lb |
| Width without Bucket | 73 in |
| Dump height | 101 in |
| Rollback - Ground Level | 35 ° |
Axles
| Tractive Effort | 8,725 lb-ft |
|---|---|
| Maximum Axle Torque | 5,698 lb-ft |
