John Deere
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Fuel Capacity | 165.9 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 76.1 gal/min |
| Hydraulic System Fluid Capacity | 76.7 gal |
| Engine Oil Capacity | 7.2 gal |
| Cooling System Fluid Capacity | 10.5 gal |
| Swing Drive Fluid Capacity | 3.2 gal |
Engine
| Engine Model | PowerTechâ„¢ PSX 9.0 L |
|---|---|
| Displacement | 549 in³ |
| Aspiration | Turbocharged air-to-air charge-air cooler |
Dimensions
| Ground Clearance | 2 in |
|---|---|
| Height - Top of Cab | 125 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 176 in |
| Width to Outside of Tracks | 134 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 8 |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 64,375 lb |
Boom/Stick Excavator Option 1
| Max Loading Height | 274 in |
|---|---|
| Max Vertical Wall Digging Depth | 217 in |
| Max Cutting Height | 394 in |
| Shipping Length of Unit | 446 in |
| Shipping Height of Unit | 137 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 292 in |
|---|---|
| Max Vertical Wall Digging Depth | 253 in |
| Max Cutting Height | 408 in |
| Max Loading Height | 285 in |
| Max Reach Along Ground | 430 in |
| Shipping Length of Unit | 442 in |
| Shipping Height of Unit | 130 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 323 in |
|---|---|
| Max Cutting Height | 424 in |
| Max Loading Height | 301 in |
| Max Vertical Wall Digging Depth | 287 in |
| Max Reach Along Ground | 459 in |
| Shipping Length of Unit | 445 in |
| Shipping Height of Unit | 143 in |
