John Deere
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Fuel Capacity | 148.0 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 42.0 gal/min |
| Hydraulic System Fluid Capacity | 85.1 gal |
| Engine Oil Capacity | 8.0 gal |
| Cooling System Fluid Capacity | 14.6 gal |
| Operating Voltage | 12 V |
| Swing Drive Fluid Capacity | 3.7 gal |
Engine
| Power Measured @ | 2,000 rpm |
|---|---|
| Net Power | 245.5 hp |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 802 lb-ft |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 128 in |
| Length of Track on Ground | 437 in |
| Tail Swing Radius | 131 in |
| Width to Outside of Tracks | 132 in |
| Digging Depth | 252 in |
| Digging Reach | 252 in |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.0 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 45 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 65,098 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 263 in |
|---|---|
| Max Reach Along Ground | 404 in |
| Max Loading Height | 276 in |
| Max Vertical Wall Digging Depth | 215 in |
| Max Cutting Height | 391 in |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 284 in |
|---|---|
| Max Vertical Wall Digging Depth | 250 in |
| Max Cutting Height | 406 in |
| Max Loading Height | 283 in |
| Max Reach Along Ground | 426 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 316 in |
|---|---|
| Max Cutting Height | 421 in |
| Max Loading Height | 302 in |
| Max Vertical Wall Digging Depth | 283 in |
| Max Reach Along Ground | 457 in |
