D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 16,700 lb |
|---|---|
| Bucket Capacity - struck | 1.80 yd³ |
| Fuel Capacity | 31.0 gal |
| Cooling System Fluid Capacity | 4.0 gal |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 13.0 gal |
| Final Drive Fluid Capacity - each | 1.6 gal |
| Breakout Force Bucket | 14,360 lb |
| Static Tipping Load | 9,200 lb |
Engine
| Engine Model | 450-C |
|---|---|
| Displacement | 219 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 65.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 164 lb-ft |
Hydraulic System
| Pump Flow Capacity | 28.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,250 psi |
| Pump Type | Gear |
Dimensions
| Height - Top of Cab | 85 in |
|---|---|
| Length with Bucket on Ground | 5 in |
| Clearance at Full Height and Dump | 103 in |
| Reach at Dump Height | 130 in |
| Length to Front of Track | 77 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 52 in |
| Number of Track Rollers per Side | 1 |
| Number of Shoes per Side | 37 |
| Ground Contact Area | 2,128 in³ |
| Length of Track on Ground | 77 in |
| Track Shoe Width | 14 in |
