John Deere
Dressta
TD-7M LGP
Crawler Dozer
37 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 29,300 lb |
|---|---|
| Fuel Capacity | 73.0 gal |
| Cooling System Fluid Capacity | 7.0 gal |
| Final Drives Fluid Capacity | 8.5 gal |
| Engine Oil Capacity | 5.0 gal |
| Hydraulic Fluid Capacity | 33.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | 300 Series |
|---|---|
| Displacement | 414 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 110.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 345 lb-ft |
Hydraulic System
| Pump Flow Capacity | 38.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,000 psi |
| Pump Type | Gear |
Dimensions
| Width Over Tracks | 120 in |
|---|
Transmission
| Transmission Type | Hydrostatic: variable speed |
|---|
