973C WH
Crawler Loader
14 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 46,255 lb |
|---|---|
| Bucket Capacity - heaped | 3.20 yd³ |
| Max Speed | 6.2 mph |
| Fuel Capacity | 95.1 gal |
| Static Tipping Load | 31,597 lb |
| Breakout Force Bucket | 36,869 lb |
| Cooling System Fluid Capacity | 5.4 gal |
| Hydraulic System Fluid Capacity | 50.7 gal |
| Final Drive Fluid Capacity - each | 4.5 gal |
| Engine Oil Capacity | 7.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | 6068H |
|---|---|
| Displacement | 415 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 181.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged w/ aftercooler |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 688 lb-ft |
Hydraulic System
| Pump Flow Capacity | 55.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,770 psi |
| Pump Type | Variable displacement piston pump with load sensing proportional pump flow control |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 131 in |
| Width to Outside of Tracks | 91 in |
| Length with Bucket on Ground | 270 in |
| Clearance at Full Height and Dump | 118 in |
| Reach at Dump Height | 48 in |
| Length to Front of Track | 192 in |
Undercarriage
| Length of Track on Ground | 102 in |
|---|---|
| Track Gauge | 71 in |
| Track Shoe Width | 20 in |
| Ground Pressure | 11 psi |
| Number of Track Rollers per Side | 6 |
| Ground Contact Area | 4,050 in³ |
| Number of Shoes per Side | 38 |
