973C WH
Crawler Loader
14 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 49,600 lb |
|---|---|
| Fuel Capacity | 88.3 gal |
| Cooling System Fluid Capacity | 10.5 gal |
| Hydraulic System Fluid Capacity | 40.0 gal |
| Final Drive Fluid Capacity - each | 6.3 gal |
Engine
| Engine Model | 500 Series |
|---|---|
| Displacement | 619 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 200.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and aftercooler |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 730 lb-ft |
Hydraulic System
| Pump Flow Capacity | 58.5 gal/min |
|---|---|
| Lower Time | 3.7 s |
| Raise Time | 6.7 s |
| Relief Valve Pressure | 2,000 psi |
| Dump Time | 1.5 s |
Dimensions
| Width to Outside of Tracks | 152 in |
|---|
