John Deere
892D LC
- Operating Weight
- 67,590 lb
- Max Digging Depth
- 270 in
- Max Digging Depth
- 292 in
- Net Power
- 195.0 hp
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Operating Weight | 67,590 lb |
|---|---|
| Fuel Capacity | 135.0 gal |
| Hydraulic Pump Flow Capacity | 144.2 gal/min |
| Hydraulic System Fluid Capacity | 87.0 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 25.0 gal |
| Cooling System Fluid Capacity | 36.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 11.0 gal |
Engine
| Engine Model | 6466A |
|---|---|
| Displacement | 466 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 205.0 hp |
| Net Power | 195.0 hp |
| Aspiration | Turbocharged with aftercooler |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 610 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 158 in |
| Tail Swing Radius | 130 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 48 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 2.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 50 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 45,410 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 270 in |
|---|---|
| Max Reach Along Ground | 408 in |
| Max Loading Height | 269 in |
| Max Vertical Wall Digging Depth | 222 in |
| Max Cutting Height | 388 in |
| Shipping Length of Unit | 434 in |
| Shipping Height of Unit | 134 in |
Bucket
| Reference Bucket Capacity | 1.80 yd³ |
|---|
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 292 in |
|---|---|
| Max Vertical Wall Digging Depth | 256 in |
| Max Cutting Height | 402 in |
| Max Loading Height | 281 in |
| Max Reach Along Ground | 430 in |
| Shipping Length of Unit | 431 in |
| Shipping Height of Unit | 131 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 323 in |
|---|---|
| Max Cutting Height | 418 in |
| Max Loading Height | 294 in |
| Max Vertical Wall Digging Depth | 291 in |
| Max Reach Along Ground | 461 in |
| Shipping Length of Unit | 433 in |
| Shipping Height of Unit | 138 in |
