John Deere

909JH

Processor

Operating Weight
77,823 lb
Lift Capacity at Max Reach
13,999 lb
Gross Power
294.0 hp
Net Power
274.0 hp
All processors/harvesters
John Deere 909JH Processor
1 / 5
Image 1 of 5
Image: rdoequipment.com

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Operating Weight77,823 lb
Max Speed2.7 mph
Fuel Capacity295.1 gal
Operating Voltage24 V
Alternator Supplied Amperage80 A
Hydraulic System Fluid Capacity82.2 gal
Cooling System Fluid Capacity11.1 gal
Engine Oil Capacity7.4 gal

Engine

Engine specifications
Engine Model6081H Tier II
Displacement492 in³
Power Measured @2,000 rpm
Gross Power294.0 hp
Net Power274.0 hp
Number of Cylinders6
Torque Measured @1,400 rpm
Max Torque885 lb-ft

Dimensions

Dimensions specifications
Height - Top of Cab158 in
Overall Width132 in
Forward Tilt27 °
Side Tilt18 °

Undercarriage

Undercarriage specifications
Ground Pressure10 psi
Track Gauge108 in
Number of Track Rollers per Side10
Shoe Size24 in
Ground Clearance30 in
Track Length194 in

Boom

Boom specifications
Lift Capacity at Max Reach13,999 lb
Max Reach w/ Head348 in
