Kato
Hitachi
EX60-5
Excavator
48 specifications
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight | 23,149 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 60.8 gal/min |
| Hydraulic System Fluid Capacity | 37.0 gal |
| Hydraulic System Relief Valve Pressure | 4,760 psi |
| Engine Oil Capacity | 3.2 gal |
| Cooling System Fluid Capacity | 4.5 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 0.6 gal |
| Alternator Supplied Amperage | 25 A |
Engine
| Engine Model | C 4D31T |
|---|---|
| Displacement | 201 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 81.9 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,700 rpm |
| Max Torque | 220 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 107 in |
| Length of Track on Ground | 103 in |
| Tail Swing Radius | 84 in |
| Width to Outside of Tracks | 98 in |
| Removal Counterweight Clearance | 35 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 79 in |
| Number of Track Rollers per Side | 6 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 20 in |
| Number of Shoes per Side | 41 |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 19,400 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 189 in |
|---|---|
| Max Reach Along Ground | 287 in |
| Max Loading Height | 220 in |
| Max Vertical Wall Digging Depth | 167 in |
| Max Cutting Height | 312 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.80 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 200 in |
|---|---|
| Max Vertical Wall Digging Depth | 179 in |
| Max Cutting Height | 319 in |
| Max Loading Height | 226 in |
| Max Reach Along Ground | 299 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 222 in |
|---|---|
| Max Cutting Height | 319 in |
| Max Loading Height | 228 in |
| Max Vertical Wall Digging Depth | 180 in |
| Max Reach Along Ground | 316 in |
