Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 43,652 lb |
|---|---|
| Tire Size | 26.5-25-20PR(L3) |
| Turning Radius | 263 in |
Engine
| Engine Model | PE6T34 |
|---|---|
| Displacement | 712 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 216.0 hp |
| Aspiration | diesel w/ turbo |
Hydraulic System
| Raise Time | 6.3 s |
|---|---|
| Lower Time | 3.5 s |
| Dump Time | 1.4 s |
Dimensions
| Height - Top of Cab | 138 in |
|---|---|
| Wheelbase | 131 in |
| Reach at Max Lift and Dump | 46 in |
| Length with Bucket on Ground | 316 in |
Transmission
| Max Speed - Forward | 21.2 mph |
|---|---|
| Max Speed - Reverse | 21.6 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.00 yd³ |
|---|---|
| Bucket Capacity - struck | 4.39 yd³ |
| Dump Clearance at Max Raise | 119 in |
| Breakout Force | 4,173 lb |
