Kawasaki
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 43,872 lb |
|---|---|
| Fuel Capacity | 76.7 gal |
| Tire Size | 23.5-25-16PR (L-2) |
| Hydraulic System Fluid Capacity | 67.1 gal |
| Static Tipping Weight | 29,970 lb |
| Operating Voltage | 24 V |
| Turning Radius | 282 in |
| Engine Oil Fluid Capacity | 9.8 gal |
| Rear Axle Oscillation | 30 ° |
| Alternator Supplied Amperage | 75 A |
| Front Axle/Diff Fluid Capacity | 14.6 gal |
| Rear Axle/Diff Fluid Capacity | 14.6 gal |
| Cooling System Fluid Capacity | 17.5 gal |
| Transmission Fluid Capacity | 15.9 gal |
Engine
| Engine Model | LT-10-C250 |
|---|---|
| Displacement | 611 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 226.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 55.7 gal/min |
|---|---|
| Raise Time | 6.3 s |
| Lower Time | 4.0 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 2,630 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 143 in |
| Wheelbase | 126 in |
| Width Over Tires | 117 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 301 in |
| Hinge Pin - Max Height | 162 in |
Transmission
| Max Speed - Forward | 22.5 mph |
|---|---|
| Max Speed - Reverse | 9.7 mph |
| Transmission Type | full power shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 4.30 yd³ |
|---|---|
| Bucket Capacity - struck | 3.70 yd³ |
| Dump Clearance at Max Raise | 117 in |
| Breakout Force | 37,080 lb |
| Bucket Width | 117 in |
