Kioti
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 7,937 lb |
|---|---|
| Fuel Capacity | 33.1 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,291 lb |
| 3 Point Hitch Type | Cat. II |
| Turning Radius | 150 in |
Engine
| Engine Model | 1104C-44T |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 90.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| PTO Power | 78.0 hp |
Hydraulic System
| Pump Flow Capacity | 12.3 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 111 in |
| Wheelbase | 91 in |
| Overall Length | 13 in |
| Tire Size | front 12.4x24 rear 18.4x34 |
| Width Outside Frame | 79 in |
Transmission
| Max Speed | 21.2 mph |
|---|---|
| Number of Forward Gears | 16 |
| Transmission Type | fully synchro shuttle |
| Number of Reverse Gears | 16 |
