Komatsu
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 16,870 lb |
|---|---|
| Fuel Capacity | 43.6 gal |
| Cooling System Fluid Capacity | 7.1 gal |
| Final Drives Fluid Capacity | 0.9 gal |
| Engine Oil Capacity | 3.3 gal |
| Hydraulic Fluid Capacity | 12.4 gal |
Engine
| Engine Model | SAA4D102E-2 |
|---|---|
| Displacement | 240 in³ |
| Net Power | 75.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Relief Valve Pressure | 2,990 psi |
|---|
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 107 in |
| Width Over Tracks | 90 in |
| Length w/ Blade | 158 in |
Transmission
| Max Speed - Forward | 5.3 mph |
|---|---|
| Max Speed - Reverse | 5.3 mph |
| Transmission Type | dual-path hydrostatic transmission |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 66 in |
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 40 |
| Standard Shoe Size | 24 in |
| Ground Contact Area | 4,061 in³ |
| Track Pitch | 65 in |
Standard Blade
| Width | 126 in |
|---|---|
| Height | 3 in |
| Blade Angle (both directions) | 25 ° |
