933C LGP
Crawler Loader
38 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 15,430 lb |
|---|---|
| Bucket Capacity - heaped | 1.10 yd³ |
| Max Speed | 4.1 mph |
| Fuel Capacity | 30.4 gal |
| Static Tipping Load | 9,770 lb |
| Breakout Force Bucket | 14,990 lb |
| Cooling System Fluid Capacity | 5.9 gal |
Engine
| Engine Model | 4D105-5 |
|---|---|
| Displacement | 264 in³ |
| Net Power | 66.0 hp |
Dimensions
| Height - Top of Cab | 107 in |
|---|---|
| Width to Outside of Tracks | 89 in |
| Length with Bucket on Ground | 159 in |
| Reach at Dump Height | 30 in |
| Clearance at Full Height and Dump | 104 in |
Undercarriage
| Length of Track on Ground | 74 in |
|---|---|
| Track Gauge | 65 in |
| Track Shoe Width | 24 in |
| Ground Pressure | 5 psi |
| Number of Track Rollers per Side | 5 |
