Komatsu
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
Komatsu
D37PX-23
- Operating Weight
- 16,887 lb
- Max Speed - Forward
- 5.3 mph
- Gross Power
- 91.0 hp
- Net Power
- 89.0 hp
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 16,887 lb |
|---|---|
| Fuel Capacity | 50.2 gal |
| Cooling System Fluid Capacity | 9.0 gal |
| Final Drives Fluid Capacity | 1.0 gal |
| Engine Oil Capacity | 3.0 gal |
| Hydraulic Fluid Capacity | 17.0 gal |
Engine
| Engine Model | SAA4D95LE-6 |
|---|---|
| Displacement | 199 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 91.0 hp |
| Net Power | 89.0 hp |
| Make | Komatsu |
Hydraulic System
| Pump Flow Capacity | 26.2 gal/min |
|---|---|
| Relief Valve Pressure | 3,974 psi |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 110 in |
| Length of Track on Ground | 89 in |
| Length w/ Blade | 169 in |
Transmission
| Max Speed - Forward | 5.3 mph |
|---|---|
| Max Speed - Reverse | 5.3 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 69 in |
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 41 |
| Number of Carrier Rollers per Side | 1 |
| Standard Shoe Size | 600 in |
| Ground Contact Area | 4,148 in³ |
