D3K LGP
Crawler Dozer
35 specifications
:quality(75)/products/10386/3d_cover/18f059cf-d332-443c-b85c-df4fb18511aa.png)
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 23,413 lb |
|---|
Engine
| Engine Model | 6D105-1 |
|---|---|
| Displacement | 396 in³ |
| Power Measured @ | 2,350 rpm |
| Gross Power | 93.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 111 in |
| Length of Track on Ground | 102 in |
| Width Over Tracks | 98 in |
| Length w/ Blade | 181 in |
| Length w/o Blade | 142 in |
Transmission
| Transmission Type | DD |
|---|---|
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 4 |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 70 in |
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 43 |
| Number of Carrier Rollers per Side | 1 |
| Standard Shoe Size | 28 in |
| Track Pitch | 7 in |
Standard Blade
| Width | 120 in |
|---|---|
| Height | 35 in |
| Capacity | 3.20 yd³ |
