Komatsu

D40P-5A

Crawler Dozer

Operating Weight
24,912 lb
Gross Power
95.0 hp
All crawler dozers
Komatsu D40P-5A Crawler Dozer
1 / 5
Image 1 of 5
Image: makana.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight24,912 lb

Engine

Engine specifications
Engine Model6D105-1
Displacement396 in³
Power Measured @2,350 rpm
Gross Power95.0 hp
Number of Cylinders6

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab111 in
Length of Track on Ground104 in
Width Over Tracks107 in
Length w/ Blade187 in
Length w/o Blade142 in

Transmission

Transmission specifications
Transmission TypeDD
Number of Forward Gears5
Number of Reverse Gears4

Undercarriage

Undercarriage specifications
Track Gauge78 in
Number of Track Rollers per Side7
Number of Shoes per Side43
Number of Carrier Rollers per Side1
Standard Shoe Size28 in
Track Pitch7 in

Standard Blade

Standard Blade specifications
Width131 in
Height36 in
