Komatsu

D40PL-3

Crawler Dozer

Operating Weight
25,133 lb
Gross Power
93.0 hp
All crawler dozers
Komatsu D40PL-3 Crawler Dozer
1 / 5
Image 1 of 5
Image: makana.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight25,133 lb

Engine

Engine specifications
Engine Model6D105-1
Displacement396 in³
Power Measured @2,350 rpm
Gross Power93.0 hp
Number of Cylinders6

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab111 in
Length of Track on Ground102 in
Width Over Tracks138 in
Length w/ Blade182 in
Length w/o Blade142 in

Transmission

Transmission specifications
Transmission TypeDD
Number of Forward Gears5
Number of Reverse Gears4

Undercarriage

Undercarriage specifications
Track Gauge90 in
Number of Track Rollers per Side6
Number of Shoes per Side43
Number of Carrier Rollers per Side1
Standard Shoe Size48 in
Track Pitch7 in

Standard Blade

Standard Blade specifications
Width159 in
Height23 in
