Komatsu
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
:quality(50)/61022/b5f2b0c4-f2be-4a9e-b7d9-a3e1fe1200a2.png)
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 24,140 lb |
|---|---|
| Fuel Capacity | 66.0 gal |
| Cooling System Fluid Capacity | 7.4 gal |
| Final Drives Fluid Capacity | 3.4 gal |
| Engine Oil Capacity | 5.0 gal |
| Hydraulic Fluid Capacity | 11.6 gal |
Engine
| Engine Model | SA6D102E-2A |
|---|---|
| Displacement | 359 in³ |
| Net Power | 110.0 hp |
| Number of Cylinders | 6 |
Hydraulic System
| Relief Valve Pressure | 2,990 psi |
|---|
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 114 in |
| Length of Track on Ground | 98 in |
| Width Over Tracks | 71 in |
| Length w/ Blade | 193 in |
Transmission
| Max Speed - Forward | 4.7 mph |
|---|---|
| Max Speed - Reverse | 5.8 mph |
| Transmission Type | komatsu HYDROSHIFT transmission |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 71 in |
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 41 |
| Standard Shoe Size | 20 in |
| Ground Contact Area | 3,930 in³ |
| Track Pitch | 70 in |
Standard Blade
| Width | 132 in |
|---|---|
| Blade Angle (both directions) | 30 ° |
