Komatsu
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 26,830 lb |
|---|---|
| Fuel Capacity | 63.5 gal |
| Cooling System Fluid Capacity | 14.6 gal |
Engine
| Engine Model | 4D130-1E |
|---|---|
| Displacement | 518 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 110.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 113 in |
| Length of Track on Ground | 88 in |
| Width Over Tracks | 93 in |
| Length w/ Blade | 180 in |
| Length w/o Blade | 143 in |
Transmission
| Max Speed - Forward | 6.1 mph |
|---|---|
| Max Speed - Reverse | 7.3 mph |
| Transmission Type | TF |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 74 in |
| Number of Track Rollers per Side | 5 |
| Number of Shoes per Side | 39 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 18 in |
| Track Pitch | 7 in |
Standard Blade
| Width | 148 in |
|---|---|
| Height | 35 in |
| Capacity | 3.70 yd³ |
