Komatsu
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 28,220 lb |
|---|---|
| Fuel Capacity | 74.0 gal |
| Cooling System Fluid Capacity | 14.6 gal |
Engine
| Engine Model | NH220-CI |
|---|---|
| Displacement | 743 in³ |
| Gross Power | 140.0 hp |
Dimensions
| Length of Track on Ground | 96 in |
|---|---|
| Width Over Tracks | 95 in |
| Length w/o Blade | 158 in |
Transmission
| Max Speed - Forward | 6.5 mph |
|---|---|
| Max Speed - Reverse | 5.7 mph |
| Transmission Type | helical gear constant mesh type |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 4 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 74 in |
| Number of Track Rollers per Side | 6 |
| Standard Shoe Size | 20 in |
Standard Blade
| Width | 157 in |
|---|---|
| Height | 41 in |
