Komatsu

D60PL-7

Crawler Dozer

Operating Weight
41,227 lb
Gross Power
170.0 hp
All crawler dozers
Komatsu D60PL-7 Crawler Dozer
1 / 5
Image 1 of 5
Image: m.made-in-china.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Operating Weight41,227 lb

Engine

Engine specifications
Engine ModelNH220-C1
Displacement743 in³
Power Measured @1,850 rpm
Gross Power170.0 hp
Number of Cylinders6

Dimensions

Dimensions specifications
Ground Clearance20 in
Height - Top of Cab120 in
Length of Track on Ground144 in
Width Over Tracks138 in
Length w/ Blade234 in
Length w/o Blade190 in

Transmission

Transmission specifications
Transmission TypeDD
Number of Forward Gears5
Number of Reverse Gears4

Undercarriage

Undercarriage specifications
Track Gauge91 in
Number of Track Rollers per Side9
Number of Shoes per Side49
Number of Carrier Rollers per Side2
Standard Shoe Size47 in
Track Pitch8 in

Standard Blade

Standard Blade specifications
Width174 in
Height38 in
