KomatsuKomatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 39,242 lb |
|---|---|
| Fuel Capacity | 83.3 gal |
| Cooling System Fluid Capacity | 11.7 gal |
| Final Drives Fluid Capacity | 7.6 gal |
| Engine Oil Capacity | 5.1 gal |
| Hydraulic Fluid Capacity | 12.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 35 A |
Engine
| Engine Model | S6D114E-1 |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 1,850 rpm |
| Net Power | 152.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 578 lb-ft |
Hydraulic System
| Relief Valve Pressure | 2,988 psi |
|---|---|
| Pump Type | closed center load sensing |
Dimensions
| Height - Top of Cab | 124 in |
|---|---|
| Length of Track on Ground | 126 in |
| Width Over Tracks | 85 in |
| Length w/ Blade | 215 in |
Transmission
| Max Speed - Forward | 6.5 mph |
|---|---|
| Max Speed - Reverse | 8.0 mph |
| Transmission Type | TORQFLOW |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 85 in |
| Number of Track Rollers per Side | 8 |
| Number of Shoes per Side | 46 |
| Standard Shoe Size | 34 in |
| Ground Contact Area | 8,451 in³ |
Standard Blade
| Width | 152 in |
|---|---|
| Height | 46 in |
| Capacity | 5.00 yd³ |
| Blade Angle (both directions) | 25 ° |
