KomatsuKomatsu
D87E-3
Crawler Dozer
41 specifications
Komatsu
D61PX-15EO
- Operating Weight
- 41,249 lb
- Max Speed - Forward
- 5.4 mph
- Gross Power
- 170.0 hp
- Net Power
- 168.0 hp
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 41,249 lb |
|---|---|
| Fuel Capacity | 103.1 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Final Drives Fluid Capacity | 7.6 gal |
| Engine Oil Capacity | 7.7 gal |
Engine
| Engine Model | SAA6D107E-1 |
|---|---|
| Displacement | 408 in³ |
| Power Measured @ | 1,850 rpm |
| Gross Power | 170.0 hp |
| Net Power | 168.0 hp |
| Number of Cylinders | 6 |
Hydraulic System
| Pump Flow Capacity | 51.6 gal/min |
|---|---|
| Relief Valve Pressure | 2,990 psi |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 125 in |
| Length of Track on Ground | 126 in |
| Width Over Tracks | 152 in |
| Length w/ Blade | 199 in |
Transmission
| Max Speed - Forward | 5.4 mph |
|---|---|
| Max Speed - Reverse | 6.8 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 126 in |
| Number of Track Rollers per Side | 8 |
| Number of Shoes per Side | 46 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 34 in |
| Ground Contact Area | 8,451 in³ |
