KomatsuKomatsu
D87E-3
Crawler Dozer
41 specifications
Komatsu
D61PX-23
- Operating Weight
- 41,138 lb
- Max Speed - Forward
- 5.6 mph
- Gross Power
- 170.0 hp
- Net Power
- 168.0 hp
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 41,138 lb |
|---|---|
| Fuel Capacity | 98.3 gal |
| Cooling System Fluid Capacity | 11.9 gal |
| Final Drives Fluid Capacity | 2.2 gal |
| Engine Oil Capacity | 7.2 gal |
| Hydraulic Fluid Capacity | 26.7 gal |
Engine
| Engine Model | SAA6D107E-2 |
|---|---|
| Displacement | 408 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 170.0 hp |
| Net Power | 168.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Make | Komatsu |
Hydraulic System
| Pump Flow Capacity | 45.2 gal/min |
|---|---|
| Relief Valve Pressure | 3,974 psi |
| Pump Type | Piston-type |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 126 in |
| Width Over Tracks | 152 in |
| Length w/o Blade | 216 in |
Transmission
| Max Speed - Forward | 5.6 mph |
|---|---|
| Max Speed - Reverse | 5.6 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 84 in |
| Number of Track Rollers per Side | 8 |
| Number of Shoes per Side | 46 |
| Standard Shoe Size | 34 in |
| Ground Contact Area | 8,451 in³ |
