Komatsu
Case
850M LT
Crawler Dozer
7 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 35,715 lb |
|---|
Engine
| Engine Model | 6D125-1 |
|---|---|
| Displacement | 674 in³ |
| Power Measured @ | 1,850 rpm |
| Gross Power | 160.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 120 in |
| Length of Track on Ground | 96 in |
| Width Over Tracks | 95 in |
| Length w/ Blade | 203 in |
| Length w/o Blade | 161 in |
Transmission
| Transmission Type | TF |
|---|---|
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Track Gauge | 74 in |
|---|---|
| Number of Track Rollers per Side | 6 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 20 in |
| Track Pitch | 8 in |
Standard Blade
| Width | 157 in |
|---|---|
| Height | 41 in |
