KomatsuKomatsu
D87E-3
Crawler Dozer
41 specifications
Komatsu
D65EX-17
- Operating Weight
- 87,100 lb
- Max Speed - Forward
- 7.2 mph
- Gross Power
- 360.0 hp
- Net Power
- 354.0 hp
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 87,100 lb |
|---|---|
| Fuel Capacity | 165.0 gal |
| Cooling System Fluid Capacity | 27.3 gal |
| Final Drives Fluid Capacity | 8.2 gal |
| Engine Oil Capacity | 9.8 gal |
| Hydraulic Fluid Capacity | 24.2 gal |
Engine
| Engine Model | SAA6D140E-6 |
|---|---|
| Displacement | 15 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 360.0 hp |
| Net Power | 354.0 hp |
| Number of Cylinders | 6 |
| Make | Komatsu |
Hydraulic System
| Pump Flow Capacity | 47.6 gal/min |
|---|---|
| Relief Valve Pressure | 3,980 psi |
| Pump Type | Piston |
Transmission
| Max Speed - Forward | 7.2 mph |
|---|---|
| Max Speed - Reverse | 8.7 mph |
| Transmission Type | TORQFLOW |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 12 psi |
|---|---|
| Number of Track Rollers per Side | 7 |
| Number of Shoes per Side | 42 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 28 in |
| Ground Contact Area | 6 in³ |
