973C WH
Crawler Loader
14 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 46,782 lb |
|---|---|
| Bucket Capacity - struck | 2.90 yd³ |
| Max Speed | 6.0 mph |
| Fuel Capacity | 105.7 gal |
| Static Tipping Load | 31,218 lb |
| Breakout Force Bucket | 39,440 lb |
Engine
| Engine Model | S6D125E |
|---|---|
| Displacement | 674 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 199.9 hp |
Dimensions
| Height - Top of Cab | 130 in |
|---|---|
| Width to Outside of Tracks | 96 in |
| Length with Bucket on Ground | 245 in |
| Clearance at Full Height and Dump | 126 in |
| Reach at Dump Height | 52 in |
Undercarriage
| Length of Track on Ground | 108 in |
|---|---|
| Track Gauge | 77 in |
| Track Shoe Width | 18 in |
| Ground Pressure | 12 psi |
| Number of Track Rollers per Side | 7 |
