KomatsuKomatsu
D51PX-24
Crawler Dozer
9 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 52,051 lb |
|---|---|
| Fuel Capacity | 118.9 gal |
| Cooling System Fluid Capacity | 20.9 gal |
Engine
| Engine Model | NT-855 |
|---|---|
| Displacement | 855 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 220.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Max Torque | 759 lb-ft |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 134 in |
| Length of Track on Ground | 108 in |
| Width Over Tracks | 103 in |
| Length w/ Blade | 268 in |
| Length w/o Blade | 185 in |
Transmission
| Max Speed - Forward | 7.0 mph |
|---|---|
| Max Speed - Reverse | 8.3 mph |
| Transmission Type | TF |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 9 psi |
|---|---|
| Track Gauge | 79 in |
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 38 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 22 in |
| Track Pitch | 9 in |
Standard Blade
| Width | 148 in |
|---|---|
| Height | 52 in |
| Capacity | 8.50 yd³ |
