Komatsu

D85E-12

Crawler Dozer

Operating Weight
41,230 lb
Max Speed - Forward
6.3 mph
Gross Power
180.0 hp
All crawler dozers
Komatsu D85E-12 Crawler Dozer
1 / 5
Image 1 of 5
Image: makana.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight41,230 lb
Fuel Capacity111.0 gal
Cooling System Fluid Capacity17.2 gal

Engine

Engine specifications
Engine ModelNH-220-CI
Displacement743 in³
Gross Power180.0 hp

Dimensions

Dimensions specifications
Length of Track on Ground121 in
Width Over Tracks103 in
Length w/o Blade181 in

Transmission

Transmission specifications
Max Speed - Forward6.3 mph
Max Speed - Reverse7.5 mph
Transmission Typeplanetary gear
Number of Forward Gears3
Number of Reverse Gears3

Undercarriage

Undercarriage specifications
Ground Pressure8 psi
Track Gauge79 in
Number of Track Rollers per Side7
Standard Shoe Size22 in

Standard Blade

Standard Blade specifications
Width143 in
Height50 in
Capacity7.80 yd³
