Komatsu
Caterpillar
973C WH
Crawler Loader
14 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 62,130 lb |
|---|---|
| Bucket Capacity - heaped | 4.20 yd³ |
| Max Speed | 6.4 mph |
| Fuel Capacity | 126.9 gal |
| Static Tipping Load | 44,530 lb |
| Breakout Force Bucket | 47,400 lb |
| Cooling System Fluid Capacity | 25.7 gal |
Engine
| Engine Model | S4D155-4 |
|---|---|
| Displacement | 783 in³ |
| Net Power | 240.0 hp |
Hydraulic System
| Lower Time | 9.6 s |
|---|---|
| Raise Time | 10.8 s |
| Dump Time | 12.0 s |
Dimensions
| Width to Outside of Tracks | 109 in |
|---|---|
| Length with Bucket on Ground | 244 in |
| Reach at Dump Height | 52 in |
| Clearance at Full Height and Dump | 128 in |
Undercarriage
| Length of Track on Ground | 121 in |
|---|---|
| Track Gauge | 89 in |
| Track Shoe Width | 20 in |
| Ground Pressure | 13 psi |
| Number of Track Rollers per Side | 7 |
