GC70K
Forklift
27 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 28,616 lb |
|---|---|
| Max Speed | 17.4 mph |
| Number of Front Wheels | 4 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
| Fuel Capacity | 68.7 gal |
| Hydraulic Tank | 47.6 gal |
Engine
| Engine Model | SAA6D107E-1 |
|---|---|
| Displacement | 408 in³ |
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,600 rpm |
| Engine Make | Komatsu |
| Power | 164.0 hp |
| Fuel Type | Diesel |
| Torque | 424 lb-ft |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 110 in |
| Overall Width | 90 in |
| Turning Radius | 158 in |
| Overall Height - mast lowered | 114 in |
| Length to Fork Face | 168 in |
| Height to Top of Overhead Guard | 110 in |
| Max Fork Height | 119 in |
| Right Angle Stack | 186 in |
Mast
| Load Capacity | 22,046 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.1 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 12 ° |
| Lower Speed | 0.9 mph |
