Toyota
Hyster
H110FT
Forklift
38 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 20,040 lb |
|---|---|
| Number of Front Wheels | 4 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
| Drawbar Pull | 10,362 lb |
| Fuel Capacity | 34.4 gal |
Engine
| Engine Model | 1KD |
|---|---|
| Displacement | 182 in³ |
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,500 rpm |
| Engine Make | TOYOTA |
| Power | 74.0 hp |
| Fuel Type | Diesel |
| Torque | 220 lb-ft |
| Battery | 12 V |
Hydraulic System
| Main pump flow standard | 33.9 gal/min |
|---|---|
| Maximum operating pressure | 2,990 psi |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 89 in |
| Overall Width | 78 in |
| Turning Radius | 130 in |
| Overall Height - mast lowered | 97 in |
| Length to Fork Face | 141 in |
| Gradeability | 30.0 % |
| Height to Top of Overhead Guard | 91 in |
| Max Fork Height | 121 in |
| Right Angle Stack | 152 in |
| Free lift | 5 in |
Transmission
| Max Speed - Forward | 11.8 mph |
|---|---|
| Max Speed - Reverse | 11.8 mph |
| Transmission Type | Powershift |
| Travelspeeds(BACKWRD)Speed range | 1 |
| Travelspeeds(FRWD)Speed range | 1 |
Brakes & Steering
| Service brake | Hydraulic |
|---|---|
| Parking brake | Hand |
Tires & Wheels
| Standard_Option_Front | — |
|---|---|
| Standard_Rear | 8.25-15-14PR |
Mast
| Load Capacity | 15,432 lb |
|---|---|
| Lift Speed | 0.9 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 12 ° |
| Lower Speed | 1.2 mph |
| Max Fork Spread | 67 in |
