Komatsu

GD670A-2C

Motor Grader

Max Power
203.9 hp
Net Power Gear 5-6
203.9 hp
All motor graders
Komatsu GD670A-2C Motor Grader
1 / 5
Image 1 of 5
Image: machinerytrader.com

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Std Operation Weight - Total34,282 lb
Tire Size14.00-24-10PR
Fuel Capacity89.9 gal

Engine

Engine specifications
Engine ModelS6D114E
Displacement505 in³
Power Measured @2,500 rpm
Number of Cylinders6
Max Power203.9 hp
Net Power Gear 5-6203.9 hp

Dimensions

Dimensions specifications
Wheelbase234 in
Overall Length333 in
Width Over Tires97 in
Height to Top of Isomount Cab122 in
Blade Base98 in
Tandem Axle Wheelbase61 in
Rear Ground Clearance12 in

Transmission

Transmission specifications
Max Speed - Forward26.2 mph
Max Speed - Reverse14.7 mph
Number of Gears - Forward6

Moldboard

Moldboard specifications
Moldboard Height28 in
Moldboard Width145 in

Front Axle

Front Axle specifications
Ground Clearance12 in

Steering System

Steering System specifications
Articulation Angle20 °
