Komatsu
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
19 data points
Engine
| Engine Model | Komatsu SAA4D107E-1-A |
|---|---|
| Gross Power | 147.6 hp |
| Net Power | 139.5 hp |
| Aspiration | Turbocharged aftercooled |
| Stroke | 5 in |
| Bore | 4 in |
| Engine Type | Water-cooled 4-cycle direct injection |
Hydraulic System
| Hydraulic System Type | HydrauMind (Hydraulic Mechanical Intelligence New Design) system closed-center system with load sensing valves and pressure compensated valves |
|---|---|
| Main pump type | Variable displacement piston |
Dimensions
| Tail Swing Radius | 109 in |
|---|---|
| Track Gauge | 88 in |
| Track length | 13 in |
Undercarriage
| Number of Track Rollers per Side | 7 |
|---|---|
| Number of Shoes per Side | 45 |
| Number of Carrier Rollers per Side | 2 |
Brakes & Steering
| Service brake | Hydraulic lock |
|---|
Fluid Capacities
| Hydraulic Tank | 35.7 gal |
|---|---|
| Swing drive | 1.9 gal |
| Final Drive | 0.9 gal |
