Komatsu
John Deere
250D II
Off-Highway Truck
5 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Tire Size | 16.00-25-24PR |
|---|---|
| Alternator Supplied Amperage | — |
Engine
| Engine Model | Cummins NTC-743-C |
|---|---|
| Displacement | 743 in³ |
| Gross Power | 280.0 hp |
Weights
| Empty Weight | 40,786 lb |
|---|---|
| Loaded Weight | 84,999 lb |
| Weight Distribution Front - loaded | 30.1 % |
| Weight Distribution Rear - loaded | 69.9 % |
| Weight Distribution Front - empty | 47.6 % |
| Weight Distribution Rear - empty | 52.4 % |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 149 in |
| Overall Length | 294 in |
| Overall Width | 126 in |
| Overall Height | 137 in |
| Dump Height | 252 in |
| Dump Ground Clearance | 19 in |
Transmission
| Max Speed | 31.1 mph |
|---|---|
| Transmission Type | TCS-41-6C Torque Converter and TORQFLOW |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 39,995.6 gal |
|---|
Dump
| Dump Angle | 65 ° |
|---|---|
| Raise Time | 8.0 s |
| Load Capacity - heaped | 19.89 yd³ |
| Load Capacity - Struck | 14.70 yd³ |
