Komatsu

PC1250LC-8

Mini Excavator

Operating Weight
250,154 lb
Max Digging Depth
369 in
Gross Power
688.0 hp
Net Power
672.0 hp
All mini excavators
Komatsu PC1250LC-8 Mini Excavator
1 / 5
Image 1 of 5
Image: komatsu.com

Specifications

38 data points

Operating Specifications

Operating Specifications specifications
Operating Weight250,154 lb
Operating Weight w/o Attachment279,163 lb
Fuel Capacity359.3 gal
Hydraulic System Fluid Capacity177.0 gal
Operating Voltage24 V
Alternator Supplied Amperage90 A
Engine Oil Capacity22.8 gal
Cooling System Fluid Capacity37.6 gal
Max Drawbar Pull154,320 lb

Engine

Engine specifications
Engine ModelSAA6D170E-5
Displacement1,413 in³
Power Measured @1,800 rpm
Gross Power688.0 hp
Net Power672.0 hp
Number of Cylinders6
Aspirationturbocharged aftercooled

Hydraulic System

Hydraulic System specifications
Pump TypeVariable-capacity piston pumps
Relief Pressure4,980 psi
Pump Capacity261.1 gal/min

Transmission

Transmission specifications
Max Speed2.0 mph
Transmission TypeHydrostatic
Number of Forward Gears2

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth369 in
Max Reach Along Ground592 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed6 rpm

Boom/Stick Mat. Handler Option 1

Boom/Stick Mat. Handler Option 1 specifications
Boom/Stick Option (MAT) 12-piece front 16.8m 55'
Max Depth264 in
Max Height728 in
Max Reach Along Ground588 in

Boom/Stick Mat. Handler Option 2

Boom/Stick Mat. Handler Option 2 specifications
Boom/Stick Option (MAT) 22-piece front 21.3m 70'
Max Depth354 in
Max Height915 in
Max Reach Along Ground839 in

Track Undercarriage

Track Undercarriage specifications
Length of Track on Ground235 in
Number of Shoes per Side55
Number of Track Rollers per Side10
Shoe Size39 in
Track Gauge155 in
