Komatsu
PC130-6
- Operating Weight
- 5,931 lb
- Max Digging Depth
- 202 in
- Max Digging Depth
- 219 in
- Net Power
- 86.0 hp
1 / 5
Image 1 of 5
Specifications
48 data points
Operating Specifications
| Operating Weight | 5,931 lb |
|---|---|
| Fuel Capacity | 60.8 gal |
| Hydraulic Pump Flow Capacity | 59.8 gal/min |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Hydraulic System Relief Valve Pressure | 4,623 psi |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 4.8 gal |
| Swing Drive Fluid Capacity | 0.7 gal |
Engine
| Engine Model | S4D102E |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 86.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 108 in |
| Length of Track on Ground | 109 in |
| Tail Swing Radius | 84 in |
| Width to Outside of Tracks | 97 in |
| Removal Counterweight Clearance | 35 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 78 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 42 |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 22,487 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 202 in |
|---|---|
| Max Reach Along Ground | 307 in |
| Max Loading Height | 233 in |
| Max Vertical Wall Digging Depth | 179 in |
| Max Cutting Height | 329 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 108 in |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 219 in |
|---|---|
| Max Vertical Wall Digging Depth | 196 in |
| Max Cutting Height | 340 in |
| Max Loading Height | 244 in |
| Max Reach Along Ground | 323 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 108 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 238 in |
|---|---|
| Max Cutting Height | 354 in |
| Max Loading Height | 258 in |
| Max Vertical Wall Digging Depth | 211 in |
| Max Reach Along Ground | 342 in |
